JinkoSolar Tiger Neo Bifacial 725 W
Exact reference · JKM725N-66HL5-BDV
High output for arrays designed around a wider module. The 725 W rating can reduce module count, but usable coverage, structure, access, 37.5 kg handling, string current and conversion-equipment limits determine whether it fits.
- Rated output
- 725 W
Front-side output at standard test conditions; annual site energy is modelled separately.
- Module efficiency
- 23.34%
Useful only when the complete wider module fits the usable array area.
- Operating point
- 41.00 V · 17.69 A
Every inverter or MPPT input and parallel-string arrangement must accept the resulting voltage and current.
- Module format
- 2384 x 1303 mm · 37.5 kg
Structure, roof coverage, access, lifting and installer handling require explicit planning.
- Rear-side response
- 80% +/-5% bifaciality
Rear-side production depends on actual irradiance and is not guaranteed by the nameplate.
Do not choose 725 W from headline power alone. Compare usable module count, total installed DC capacity, structural limits, handling and access, string voltage and current, connector variant, exact availability and modelled rear-side conditions.
MAD 1,320.00
Indicative price, TTC — The written quote confirms the exact reference, required accessories, compatibility, delivery and commercial terms.
Line total: MAD 1,320.00
Availability confirmed in your written quote
1
01 · Product role
What this product does in the system.
The JKM725N-66HL5-BDV converts front and rear irradiance into DC electricity and operates as part of a designed module string. Its 725 W rating is measured from the front side at standard test conditions, not a promise of annual production. ReneWave places the exact module into a complete mounting, string, protection and conversion design before quotation.
Relevant applications
- Large commercial and industrial roofs where the 2384 x 1303 mm format fits the usable layout
- Ground-mounted photovoltaic arrays designed around the exact string voltage and current
- Bifacial layouts where mounting geometry and rear irradiance can be modelled from project evidence
Why ReneWave may shortlist it
- 725 W front-side STC output can reduce repeated module, mounting and connection points for a target array capacity.
- N-type TOPCon bifacial dual-glass construction supports front and separately modelled rear-side production.
- The exact 66HL5-BDV family has a current official datasheet and applicable installation, handling and warranty records.
- Its electrical and mechanical data support a traceable module, string, protection and warranty file.
What changes in practice
- Higher module power can reduce module count, but the 1.303 m width can produce a worse usable layout than a narrower module on some roofs.
- The 37.5 kg module requires planned delivery access, lifting and two-person handling appropriate to the site method.
- The 17.69 A operating current and 18.74 A short-circuit current must be checked against every inverter or MPPT input and parallel-string arrangement.
- Rear-side energy contributes only when the actual mounting and surrounding surfaces allow irradiance to reach the rear glass.
System position
From sunlight to useful energy.
String design, conversion equipment, protection and optional storage are confirmed for the complete project.
The module supplies DC. Separate compatible conversion equipment serves the protected loads.
Read the technical explanation
The JKM725N-66HL5-BDV is the 725 W member of JinkoSolar's Tiger Neo bifacial dual-glass family. It produces DC electricity from front and rear irradiance and must be integrated into a designed string, mounting, protection and conversion architecture.
Its 23.34% efficiency and 2384 x 1303 mm format can reduce module count for a target capacity, but headline watts do not decide the array. ReneWave confirms usable coverage, structure, access, lifting, cold string voltage, current limits, connector variant and rear-side assumptions before the exact reference enters a proposal.
The retained project record includes the approved datasheet, string layout, protection basis, serial and batch evidence, and the applicable warranty pack.
02 · Specifications
Ratings, dimensions and practical consequence.
Electrical ratings at front-side STC
- Nominal power
725 W
- Module efficiency
23.34%
- Maximum-power point
41.00 V · 17.69 A
- Open circuit / short circuit
49.20 V · 18.74 A
Cold-voltage and current multipliers are applied during string and protection design.
- Power tolerance
0 to +3%
- Maximum system voltage
1500 V DC
- Maximum series fuse
35 A
Construction and handling
- Cell technology
N-type monocrystalline TOPCon · 132 half cells (66 x 2)
- Construction
Framed bifacial dual-glass · 2.0 mm front and rear glass
- Dimensions
2384 x 1303 x 33 mm
- Weight
37.5 kg
- Junction box
IP68
- Output leads
+400 mm / -200 mm or documented supplied configuration
- Connector
JK03M, JK03M2 or documented supplied variant
MC4 and MC4-EVO2 are optional variants; the delivered mating path is confirmed before quotation.
- Published test loads
5400 Pa front · 2400 Pa rear
The approved mounting configuration and project design loads still control.
Thermal and operating record
- Operating temperature
-40°C to +70°C
- Power temperature coefficient
-0.29% / °C
- Voltage temperature coefficient
-0.25% / °C
- Current temperature coefficient
+0.045% / °C
- Protection class
Class II
Bifacial and warranty basis
- Power/current bifaciality
80% +/-5%
- Voltage bifaciality
98% +/-5%
- Rear-side gain
Project-modelled
Mounting height, tilt, albedo, row spacing and structure shading determine usable gain.
- Published warranty
12-year product · 30-year linear performance
The exact model, market, sale date, installation conditions and delivered warranty document control.
03 · Confirm before quotation
Four checks before this reference is quoted.
ReneWave confirms the electrical context, connected equipment, installation conditions and configuration path before the exact reference enters a written quote.
- 01
Array and structure
Confirm usable area, shading, orientation, access, module count, clamp zones, structure, 37.5 kg handling and project design loads.
- 02
Inverter and strings
Check cold Voc, operating-voltage window, 17.69 A Imp, 18.74 A Isc, parallel strings and DC/AC ratio against exact equipment.
- 03
Installation path
Confirm the delivered connector variant, conductors, isolation, protection, earthing and mounting instructions.
- 04
Traceability
Retain the complete suffix, serial and batch evidence, approved datasheet, string layout and applicable warranty pack.
04 · Documents & warranty
Keep the exact reference traceable.
Documents shown here support selection and handover. The accepted order and exact manufacturer warranty document control.
JinkoSolar Global Photovoltaic Module Installation Manualinstallation · Global · EnglishA1.8 · May 2026 · product family
JinkoSolar Photovoltaic Module Storage and Unpacking Instructionsinstallation · Global · EnglishApril 2024 · current manufacturer library edition · product family
JinkoSolar Global Bifacial Module Limited Warrantywarranty · Global · delivered terms apply · EnglishEN20260801 · 12-year product / 30-year performance · product family
Manufacturer warranty reference
12-year product · 30-year linear performance
- Published first-year degradation does not exceed 1%.
- Published annual degradation after year one does not exceed 0.40%.
- Published warranted output reaches 87.4% at year 30.
